CUETO: The grouts were not properly installed
Please log in to add to collections.
Engineering Catastrophes

The grouts were notproperly installed below the shim plates, so you don't...

CUETO: The grouts were not
properly installed below the shim plates, so you don't adequately
transfer the compressive load from the columns to
the foundation

Full Transcript

00:00:01.000 --> 00:00:03.099
CUETO: The grouts were not properly installed
00:00:03.099 --> 00:00:04.633
below the shim plates,
00:00:04.007 --> 00:00:06.007
so you don't adequately transfer the compressive load
00:00:06.008 --> 00:00:08.006
from the columns to the foundation.
